Reverse Components Base Pedals
RRP
Code: 3022
Reverse Components Base Pedals
Big, wide and grippy. The Base is Reverse's latest pedal that combines knowledge from almost 20 years of pedal manufacturing with a new technology to improve longevity: The "Baurillium" bushing from Reverse.
The newly developed "Baurillium" bushing ensures a long-lasting and low-maintenance pedal. The bushing replaces plastic or Teflon bushings with a special metal alloy with particularly effective sliding and lubricating properties. This bushing is significantly more resilient and has a long service life. A permanent lubrication is generated by the metal alloy with micro pores.
A large platform with an optimum concave keeps your foot firmly sitting into the pedal. This allows a direct feedback into the bike and stops any accidental foot slips.
Through the design stage Reverse experimented with different shaped platforms and chose a slightly rounder edge-profile of the pedal body to deflect hits and to reduces getting hung up on roots or rocks. The milled pedal body made of 6061-T6 aluminium with our proven CrMo steel axle makes for a super robust and reliable pedal.
The extra pronounced thread on the pins provides additional support and securely anchors your shoe sole to the pedal. Various pin lengths (9mm & 13mm) are optionally available as accessories to personalize the desired grip level (sold seperatley).
Whether you're hitting the steeps of Champery in the wet, big hucks in your local bike park, or taming fast, root infested natural trails, the Base keeps your feet glued to in place.
Features:
- Pedal size: 116 x 104 mm
- Contact Surface: 106 x 104 mm
- Height: 20 mm
- Pedal thread: 9/16"
- Surface: Concave Shape with additional CNC machining for the perfect grip
- Bearings: 1 x industrial bearing / 1 x Reverse-Baurillium-bushing
- Pin setup: 16 (11mm) steel pins per pedal (Thread: US size 6/32", Length: 11mm)
- Pin height: 6 mm standover height with 11mm standard pins
- Weight: 420 g (+/- 5% weight tolerance)
- Material: Aluminium (pedal) / CrMo-steel (axle) / Steel (Pins)
Extras:
- All spare parts are available separately
- High strength CrMo-steel axle
- 2 x Pedal washers: to protect the crankset thread
Safety note: Unless otherwise specified by the crank manufacturer, make sure that the pedals are tightened to min. 37 to max. 42 Nm.
